Place of Origin:
China
Brand Name:
ANNEC
Certification:
ISO, CE
Model Number:
JM23
High Quality Ivory White JM 23 Fireclay High Alumina Insulating Brick For HBS
Description of High Quality Ivory White JM 23 Fireclay High Alumina Insulating Brick For HBS.
IHigh Quality Ivory White JM 23 Fireclay High Alumina Insulating Brick For HBS is a kind of insulation brick which is made of mullite and bauxite as main raw material, it's classification temperature can be reached 1360℃,which is widely used in insulating layer of high thermal kilns and stoves.
JM 23 Fireclay Insulation Brick:
Item | JM20 | JM23 | JM26 | JM28 | JM30 | JM32 | |
USA Brand | IFB2000 | IFB2300 | IFB2600 | IFB2800 | IFB3000 | IFB3200 | |
Classification Temperature (ºC) | 1000 | 1260 | 1430 | 1540 | 1650 | 1760 | |
Bulk Density (g/cm3) | 0.52 | 0.55-0.60 | 0.78 | 0.88 | 1.03 | 1.25 | |
Cold Crushing Strength (Mpa) | 0.8 | 1.2 | 1.6 | 2.1 | 2.5 | 3.5 | |
Modulus of Rupture (Mpa) | 0.6 | 0.9 | 1.4 | 1.6 | 2.1 | 2.1 | |
Reheating Linear Change (%) CT-30 ºCX 8H | 1065 ºC 0 |
1230ºC 0 |
1400ºC -0.5 | 1510ºC -0.8 | 1620ºC -0.9 | 1730ºC -0.9 |
|
Thermal conductivity(W/m.k) | 400ºC | 0.17 | 0.17 | 0.24 | 0.30 | 0.40 | 0.49 |
600ºC | 0.19 | 0.19 | 0.27 | 0.32 | 0.42 | 0.50 | |
800ºC | 0.22 | 0.22 | 0.30 | 0.35 | 0.44 | 0.51 | |
1000ºC | 0.24 | 0.25 | 0.32 | 0.38 | 0.45 | 0.53 | |
Al2O3 (%) | 45 | 37 | 54 | 64 | 72 | 77 | |
Fe2O3 (%) | 0.9 | 1.0 | 0.9 | 0.8 | 0.7 | 0.5 | |
SiO2 (%) | 50 | 50 | 42 | 32 | 26 | 22 |
High Quality Ivory White JM 23 Fireclay High Alumina Insulating Brick For HBS is one kind of High-alumina refractory bricks.
One of the important working properties of High-alumina refractory bricks is the structural strength at high temperatures. The high-temperature creep properties are also measured to reflect the high-temperature structural strength. From the test, we knew that, with the increase of the Al2O3 content, the structural strength also become higher.
When the content of Al2O3 less than 70%, the load softening temperature depends on the quantity ratio between the mullite crystal phase and liquid phase. With the increase in the quantity of mullite, It also increased. Therefore, reducing the content of impurities in the raw materials is beneficial to improve the quality of the High alumina refractory bricks.
High Quality Ivory White JM 23 Fireclay High Alumina Insulating Brick For HBS Fireclay Insulation Brick refers to a heat-insulating refractory product made of bauxite with an Al2O3 content of not less than 48%.
Features:
1. Excellent strength at ambient and elevated temperatures.
2. High compressive strength.
3. Very low levels of iron and other impurities.
4. Lightweight and energy-efficient.
5. Lower heat storage than denser refractory.
6. Heats quickly and economically to operating temperature.
Application:
High Quality Ivory White JM 23 Fireclay High Alumina Insulating Brick For HBS Fireclay Insulation Brick are widely used in thermal equipment in metallurgy, petrochemical, machinery, electric power, building materials, aerospace, shipbuilding and other industrial sectors.
Zhengzhou Annec CO., Ltd. was founded in 2003, and has been a NASDAQ listed corporation since 2011 with ticker identification ANNC. Annec had become the industrial leader within China in the areas of refractory production, Engineering for hot blast stove of blast furnace, and capability for EPC project. Annec has its own Provincial Enterprise Technology Center and Top Combustion Hot Blast Stove Research Centre, Annec (Beijing) Engineering & Technology Co., Ltd and four Manufacturers for Refractories. The annual output of different type of refractories can reach 150 thousand tons, and undertaken capability of more than 10 turnkey projects for hot blast stove.
