ANNEC has capability of manufacturing refractories materials of fireclay, high alumina, silica and insulating bricks and corresponding unshaped refractories for hot blast stove. Meanwhile, ANNEC also produce various refractories for coking, sintering, casting house, torpedoes, iron ladles and steel ladles. ANNEC’s products have been sold to America, Japan, Korea, India, Iran, Vietnam, Turkey, Malaysia and Indonesia; get the customer's endorsement in the domestic and world. At the same time, ANNEC’s testing center shoulder examinations of products quality and tests of new product development.
I）
FuLiang factory is one branch mill of Zhengzhou ANNEC industrial Co.,LTD. This Plant covers an area 76000㎡ and has more than 500 employees. The mainly product are High Alumina bricks series, Fireclay Bricks series and Carbon products. The capacity is 80000 ton per year.
The facility and equipment as follow:
| FACILITY | MODEL | QUANTITY(UNIT) |
| JAW CRUSHER | PE-400×600 | 7 |
| PE-250×400 | 12 | |
| Walled Belt Conveyor | DT-500 | 4 |
| Roll Crushing Mill | 2KGP-610 | 8 |
| Cone Crusher | PYD900 | 6 |
| GYH | CX2-60 | 20 |
| RAYMOND MILL | 4R3216 | 5 |
| 5R3216 | 4 | |
| BALL GRINDING MILL | H36 | 1 |
| Electronic Batching Truck | 0.6t-1T | 4 |
| Muller | S114 | 16 |
| Wet Pan Mill | XGS2100/900-1200 | 1 |
| Orbital-motion Mixer | HNX-750Q | 2 |
| Brick Machine | J67-400T | 8 |
| J67-315T | 28 | |
| J67-630 T | 4 | |
| 1000T | 1 | |
| Hydraulic Vibration Former | ZD-200T | 2 |
| Hydraulic Vibration Former | ZD-500T | 3 |
| High Temperature Tunnel Kiln | 179m | 1 |
| High Temperature Tunnel Kiln | 313m | 1 |
| High Temperature Shuttle Kiln | 75m3 | 2 |
| Pushed Slab Kiln | 40m | 3 |
| Moulding CNC | CK6136e | 2 |
| Moulding CNC Milling Machining | J1VMC50mb | 2 |
| Sr | EQUIPMENT | MODEL | QUALITY | APPLICATION |
| 1 | Fire Resistance Test Furnace | NHD-02 | 1 | refractoriness |
| 2 | reheat testing furnace | CSC-16-12 | 1 | re-burning line |
| 3 | high temperature creep tester | XCSL-16-36Y | 3 | soft load, creep |
| 4 | high temperature load soft tester | HRY-02XP | 1 | soft load |
| 5 | strength tester | NYL-600 | 2 | CCS |
| 6 | compression tester | TYE-2000E | 1 | CCS |
| 7 | vacuum drier | DZ-1AII/DE-IBC型 | 5 | AP, BD |
| 8 | sampling machine | 全自动 | 2 | sampling |
| 9 | thermal shock test furnace | KRZ-S01 | 1 | thermal shock resistance |
| 10 | automatic thermal dilatometer | RPZ-13-20 | 1 | thermal expansion |
| 11 | could bending strength tester |
DKZ-6000 | 2 | could bending strength |
| 12 | industrial balance | KF0002 | 2 | AP, BD |
| 13 | 1/10000 balance | FA1004 | 2 | weight |
| 14 | drying oven | WGL-65B | 3 | physical & chemical drying sample |
| 15 | sealed vibrating mill | MZ-100 | 1 | chemical analysis |
| 16 | sealed crusher | PE-60X100 | 3 | chemical analysis |
| 17 | electric constant temperature bath | DK-98-1 | 1 | chemical analysis |
| 18 | resistance furnace | SRJX-4-13 | 2 | melting sample |
| 20 | flame photometer | 6400A | 3 | chemical analysis |
| 21 | high temperature bending strength tester | HMOR-02QP | 1 | high temperature bending strength |
| 22 | electronic multi-purpose furnace | 220VA 1000W | 3 | chemical analysis |
| 23 | multi-element analysis meter | DHF83 | 2 | chemical analysis |
| 24 | 2500m3 could-state simulation device | ANNECSY-1 | 1 | temperature,air & pressure distribution;flame length |
| 25 | 5500m3 hot-state simulation device | ANNECSY-2 | 1 | temperature,air & pressure distribution;flame length |
II）
Fuhua factorhy is another one branch mill of Zhengzhou ANNEC industrial Co.,LTD. This plant covers an area 3500㎡ and has 240 employees. The mainly product are Silica bricks series, and unshaped products. The capacity is 60000 ton per year.
The facility and equipment as follow:
| FACILITY | model | QUANTITY（UNIT） |
| GYH | CX2-60 | 4 |
| Electronic Batching Truck | 0.6t-1T | 2 |
| Muller | S114 | 8 |
| Wet Pan Mill | XGS2100/900-1200 | 1 |
| Wheel Mixer | LNX-1600 | 1 |
| Orbital-motion Mixer | HNX-750Q | 3 |
| Brick Machine | J67-315T | 42 |
| Hydraulic Vibration Former | ZD-200T | 1 |
| Hydraulic Vibration Former | ZD-500T | 2 |
| High Temperature Tunnel Kiln | 190m | 2 |
| Sr | EQUIPMENT | MODEL | QUANTITY(UNIT) | APPLICATION |
| 1 | Vacuum Drier | DZ-1AII/DE-IBC | 1 | AP, BD |
| 2 | Sampling Machine | AUTO | 1 | sampling |
| 3 | Industrial Balance | KF0002 | 1 | AP, BD |
| 4 | 1/10000 Balance | FA1004 | 1 | weight |
| 5 | Drying Oven | WGL-65B | 1 | physical & chemical drying sample |
| 6 | Resistance Furnace | SRJX-4-13 | 1 | melting sample |
| 7 | Spctrophotometer | 723 | 1 | chemical analysis |
| 8 | Electronic Multi-purpose Furnace | 220VA 1000W | 1 | chemical analysis |
| 9 | Multi-element Analysis Meter | DHF83 | 1 | chemical analysis |
ANNEC has been providing matched refractories of different type HBS for CERI, CISDI, WISDRI, CSGI and Kalugin，P·W，Danieli and SIEMENS VAI in their worldwide projects. ANNEC is awarded as excellent supplier by Baosteel, CSGI, and MCC etc. WE own very mature Production line.
