Product Details:
Place of Origin: China
Brand Name: Annec
Model Number: RG-95
Payment & Shipping Terms:
Minimum Order Quantity: 5 Tons
Price: 400-2500 USD/T
Packaging Details: 12-24 pallets for one 20 GP container
Delivery Time: 50-120 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3500 Tons/ per month

Light Weight Insulating Silica Brick Refractory Brick Mullite for Thermal Insulation 0.8-1.2 G/cm3

Description
Al2O3: ≤1.0% Fe2O3: ≤1.3%
Apparent Porosity: ≤22(24)% Bulk Density: ≤2.32 G/cm3
Characteristics: Acid Refractory Material Cold Crushing Strength: ≥45(35)MPa
Residual Quartz: ≤1.0 % Refractoriness Under Load, T0.6: ≥1650 ℃
Thermal Conductivity,1000℃: ≤1.25 %
High Light:

Checker Silica Refractory Bricks

,

1.3% Fe2O3 Silica Refractory Bricks

,

Alumina Silica Checker Fire Brick

Light Weight Insulating Silica Brick Refractory Brick Mullite for Thermal Insulation 0.8-1.2 G/cm3

Definition:

Light Weight Insulating Silica Brick Refractory Brick Mullite for Thermal Insulation 0.8-1.2 G/cm3  refer to heat-insulating refractory products made of silica as the main raw material and with an SiO2 content of not less than 91%. In addition to the thermal insulation properties of Insulating silica bricks, Light Weight Insulating Silica Brick Refractory Brick Mullite for Thermal Insulation 0.8-1.2 G/cm3 maintains the characteristics of silicon bricks to a large extent. The starting temperature of load softening is high, and the volume expands slightly during the heating process, which enhances the integrity of the kiln. The manufacture of siliceous Insulating silica bricks uses finely pulverized silica as the raw material, adding part of the waste silica bricks or waste siliceous Insulating silica bricks powder, mineralizers and burnout additives. Add water to the mixer according to a certain proportion to mix into a mud, which is formed by mechanical or manual molding. After the brick is dried, the residual moisture is less than 0.5% before it can be loaded into the kiln. In order to prevent the violent volume expansion due to the polycrystalline transformation of SiO2, causing cracks in the product, a slower temperature rise and fall speed are required during firing.



Light Weight Insulating Silica Brick Refractory Brick Mullite for Thermal Insulation 0.8-1.2 G/cm3 is a kind of high temperature insulating refractory material. It is made of refractory clay clinker as raw material, plastic clay as binder, adding appropriate amount of combustible or foaming agent, forming by brick press, and then sintering. The light insulation brick is generally used in the thermal insulation layer of high temperature kilns as thermal insulation material.

Light Weight Insulating Silica Brick Refractory Brick Mullite for Thermal Insulation 0.8-1.2 G/cm3, with its high porosity, low bulk density and good thermal insulation performance, is widely used as the thermal insulation filling material between refractory brick and ketone body in various industrial kilns to reduce heat loss and obtain high energy utilization efficiency.





Advantage:



    (1) Refractoriness under load:

    The refractoriness under load of Alumina Silica Checker Fire Brick is higher than that of clay brick and high aluminum brick, reaching 1640 ~ 1670℃, which belongs to advanced refractory materials.



    (2) Thermal conductivity:

    Alumina Silica Checker Fire Brickhas better thermal conductivity than clay brick and high aluminum brick



Application:



  Alumina Silica Checker Fire Brick is mainly used for the partition of coking chamber and combustor of coke making furnace, regenerator chamber and cinder chamber of steelmaking open hearth furnace, soaking pit, refractory material of glass melting furnace and sintering furnace of ceramics and other kiln vault and other load-bearing parts.

It is also used for high temperature load bearing parts of hot blast furnace and acid open hearth furnace top.



Product Description:

Alumina Silica Checker Fire Brick
Item Unit RG-95 JG-1 JG-2
SiO2 % ≥95 ≥94.5 ≥94.5
Al2O3 % ≤1.0 ≤1.5 ≤1.5
Fe2O3 % ≤1.3 ≤1.5 ≤1.5
CaO % - ≤2.5 ≤2.5
Apparent Porosity % ≤22(24) ≤22 ≤24
Bulk Density g/cm3 ≤2.32 - -
Ture Bulk Density g/cm3 - ≤2.33 ≤2.34
Cold Crushing Strength Mpa ≥45(35) ≥40 ≥35
Residual Quartz % ≤1.0 ≤1.0 ≤1.0
Refractoriness under load, T0.6 ≥1650 ≥1650 ≥1650
Creep Rate(1550℃X50h ,0.2MPa) % ≤0.8 - -
Thermal conductivity,1000℃ % ≤1.25 ≤1.28 ≤1.3
Linear Change on Reheating(1450℃×2h) % - 0~0.3 0~0.3
