High Grade Bauxite Al2O3 48% High Alumina Refractory Bricks

High Grade Bauxite Al2O3 48% High Alumina Refractory Bricks

Al2O3 48% High Alumina Refractory Bricks

Bauxite High Alumina Refractory Bricks

Bauxite Alumina Refractory Bricks

Place of Origin:

China

Brand Name:

Annec

Contact Us
Request A Quote
Product Details
Al2O3:
≥50
Apparent Porosity:
≤23
Cold Crushing Strength:
≥50
Creep Rate(0~50h ,0.2MPa):
1270℃~1550℃, 0.8
Linear Change On Reheating:
1420℃~1550℃ 0.1~-0.4
Raw Mterial:
Bauxite
Highlight:

Al2O3 48% High Alumina Refractory Bricks

,

Bauxite High Alumina Refractory Bricks

,

Bauxite Alumina Refractory Bricks

Payment & Shipping Terms
Minimum Order Quantity
5 Tons
Price
400-2500 USD/T
Packaging Details
12-24 pallets for one 20 GP container
Delivery Time
50-120 days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
7500 Tons/ per month
RELATED PRODUCTS
Contact Us
86-0371-69938888
Contact Now
Product Description

High Grade Bauxite Al2O3 48% High Alumina Refractory Bricks



Definition:

   High Alumina Andalusite Fused Mullite Refractory Bricks is a kind of refractory material. The main component of this refractory brick is Al2O3.


    Due to different resources, national standards are not completely consistent. For example, European countries stipulate that the lower limit of Al2O3 content for high aluminum refractory is 42%.


    In China, the Al2O3 content in high-alumina bricks is usually divided into three grades: Ⅰ etc.-Al2O3 content> 75%; Ⅱ etc.-Al2O3 content is 60 ~ 75%; III etc.-Al2O3 content is 48 ~ 60%.



     Low Creep High Alumina Refractory Bricks is a neutral refractory with alumina content above 48%.


    It is formed by calcining alumina and other raw materials with high alumina content. High thermal stability, fire resistance above 1770℃. It has good slag resistance and is used for lining steel-making electric furnaces, glass melting furnaces, cement rotary furnaces, etc.


    High-load soft, low-creep high-alumina brick is a high-grade refractory material made of super-grade alumina, fused corundum, and fused mullite as the main raw materials.




Advantage:



Competitive Price. Make the products competitive in your market.

Abundant Experience. Prevent cracks and twist in bricks.

Different Moulds. Save mould fees for you.

Strict Quality Control.

Meet clients’ quality requirement.

Large stocks. prompt delivery.



Application:



 High Alumina Andalusite Fused Mullite Refractory Bricks mainly used for the insulating lining of hot surfaces or backing heat-insulating layers of other
refractory materials. The refractory linings or heat-insulating materials of the industries, such as, ethylene pyrolysis furnaces, ubular furnaces, reforming furnaces of synthetic ammonia, gas generators and high-temperature shullte kilns, etc.



Product Description:

High Alumina Andalusite Fused Mullite Refractory Bricks
Item Unit DRL-155 DR-150 DRL-145 DRL-140 DRL-135 DRL-130 DRL-127
Al2O3 % ≥75 ≥75 ≥65 ≥65 ≥65 ≥60 ≥50
Apparent Porosity % ≤20 ≤21 ≤21 ≤22 ≤22 ≤22 ≤23
Bulk Density % 2.65~2.85 2.65~2.85 2.5~2.7 2.4~2.6 2.35~2.55 2.3~2.5 2.3~2.5
Cold Crushing Strength Mpa ≥60 ≥60 ≥60 ≥55 ≥55 ≥55 ≥55
Creep Rate(0~50h ,0.2MPa)  %  1550℃
0.8
1500℃
0.8
1450℃
0.8
1400℃
0.8
1350℃
0.8
1300℃
0.8
1270℃
0.8
Linear Change on Reheating % 1550℃×2h
0.1 ~ -0.2
1550℃×2h
0.1 ~ -0.2
1550℃×2h
0.1 ~ -0.2
1450℃×2h
0.1 ~ -0.2
1450℃×2h
0.1 ~ -0.4
1450℃×2h
0.1 ~ -0.4
1450℃×2h
0.1 ~ -0.4





High Grade Bauxite Al2O3 48% High Alumina Refractory Bricks 0

Packaging and shipping

Standard packing: waterproof inner packing + outer packing suitable for container transportation

High Grade Bauxite Al2O3 48% High Alumina Refractory Bricks 1
