Refractory Manufacturer fireplace silica brick refractory for wood stove high density silica insulating fire bricks

Refractory Manufacturer fireplace silica brick refractory for wood stove high density silica insulating fire bricks
Refractory Manufacturer fireplace silica brick refractory for wood stove high density silica insulating fire bricks Refractory Manufacturer fireplace silica brick refractory for wood stove high density silica insulating fire bricks Refractory Manufacturer fireplace silica brick refractory for wood stove high density silica insulating fire bricks

Large Image :  Refractory Manufacturer fireplace silica brick refractory for wood stove high density silica insulating fire bricks

Product Details:
Place of Origin: China
Brand Name: Annec
Certification: iso
Payment & Shipping Terms:
Minimum Order Quantity: 5 Tons
Price: 400-1000 USD/T
Packaging Details: 12-24 pallets for one 20 GP container
Delivery Time: 50-120 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1500 Tons/per tons

Refractory Manufacturer fireplace silica brick refractory for wood stove high density silica insulating fire bricks

Description
SiO2 %: ≥91 Bulk Density ( G/cm3): ≤1-1.2
Cold Crushing Strength (MPa): ≥2-5 Refractoriness Under Load 0.1MPa, ℃: ≥1400-1520
Thermal Conductivity(350±25)℃ (W/mK): ≤0.55-0.7 Origin: Henan China
High Light:

1520C Silica Insulating Brick

,

1400C Silica Insulating Brick

,

1400C Lightweight Insulating Brick

High Refractoriness 1400C 1520C Silica Insulating Brick



Item GGR-1.0 GGR-1.10 GGR-1.5 GR-1.2
SiO2 % ≥91 ≥91 ≥91 ≥91
Bulk Density ( g/cm3) ≤1 ≤1.1 ≤1.15 ≤1.2
Cold Crushing Strength (MPa) ≥2 ≥3 ≥5 ≥5
Linear Change on Reheating(%) 1550℃, 2h - - ≤0.5 ≤0.5
1450℃,2h ≤0.5 ≤0.5 - -
Refractoriness Under Load
0.1MPa, ℃
≥1400 ≥1420 ≥1500 ≥1520
Thermal conductivity(350±25)℃ (W/mK) ≤0.55 ≤0.60 ≤0.65 ≤0.70



Definition:



Light Weight Silica Insulating Brick are also known as silica insulating bricks. Lightweight refractory with more than 91% silica and a bulk density of less than 1.2 g / cm3. Fire resistance and load softening temperature are not much different from ordinary silicon bricks of the same composition.



However, due to the large number of pores, the compressive strength, slag resistance, and corrosion resistance are inferior to ordinary silicon bricks, but the thermal shock resistance is improved.


When using finely divided silica as a raw material, the critical particle size is usually less than 1 mm and 90% or more of particles less than 0.5 mm. Add flammable substances to the material or use the gassing method to form the porous structure obtained by firing. It can also be made of non-combustible material.



Light Weight Silica Insulating Brick are mainly used in various parts of the kiln, require insulation or do not come into direct contact with the melt, without the action of positive gases or with abrupt temperature changes Without reducing your own weight. When used at high temperatures, do not come into contact with alkaline refractories. The maximum operating temperature is 1200-1550℃, depending on the material.



Light Weight Silica Insulating Brick manufacturing process:

Light Weight Silica Insulating Brick : crushing → mixing → molding → drying → firing → inspection → packing and shipping

Lightweight, Light Weight Silica Insulating Brick have the advantages of high porosity, good thermal insulation, high mechanical strength, low heat resistance fiberboard conductivity and long service life. It has high cold crush strength, size accuracy and currently has the most stable and lowest thermal conductivity of all adiabatic refractory bricks. Its highest insulation castable service temperature is 1350℃. Improve thermal efficiency and working conditions, reduce energy consumption, achieve productivity and important economic results.


Light Weight Silica Insulating Brick have a low bulk density. The total weight and wall thickness of the furnace can be effectively reduced.
It finds wide application in ceramic tunnel kilns, roller kilns, shuttle kilns, coking furnaces in the steel industry and other thermal equipment. Mainly used for lining and insulating layers in areas that are not strongly eroded by high temperature melts. When in direct contact with a flame, the surface contact temperature cannot exceed 1350°C.



Advantage:



1.The high temperature volume is stable, and the furnace body does not change due to the temperature fluctuation surface. Because the silicon brick has a high load softening temperature and a small creep rate, the glass kiln can keep the furnace body from deforming at 1600 ° C, and the structure is stable.



2.No pollution to the glass liquid. The main component of silica brick is SiO2. If it is used, if there is any drop or surface droplet, silica bricks for glass melting furnace will not affect the quality of the glass liquid.



3.Resistance to chemical attack. The superstructure silicon brick is eroded by R2O gas in the glass batch, and a smooth metamorphic layer is formed on the surface, which makes the erosion speed lower and protects.



4. The bulk density is small, which can reduce the weight of the furnace body



Silica bricks are used in the roof and superstructure of glass melting tanks as well as for hot repairs.



Application:



Light Weight Silica Insulating Brick are used in the blast furnace blast area and communicate with the blast furnace exhaust. The light silicon bricks have a temperature range of 1000 ~ 1300 ℃. Can meet the whole cycle life of hot blast stove


Light Weight Silica Insulating Brick are also used in the partition walls of the carbonization and combustion chambers of coke ovens, the regenerators and slag chambers of open hearth furnaces, soaking furnaces, glass melting furnaces, refractory materials and ceramic firing kilns. There are also vaults and other load-bearing parts for kilns. It is also used for the high-temperature load-bearing part of hot blast stove and the top of acidic open hearth furnace.

Refractory Manufacturer fireplace silica brick refractory for wood stove high density silica insulating fire bricks 0Refractory Manufacturer fireplace silica brick refractory for wood stove high density silica insulating fire bricks 1Refractory Manufacturer fireplace silica brick refractory for wood stove high density silica insulating fire bricks 2Refractory Manufacturer fireplace silica brick refractory for wood stove high density silica insulating fire bricks 3
