Place of Origin:
China
Brand Name:
Annec
Certification:
ISO
Definition:
Fired Clay Refractory Industiral Brick are alumina silicate bricks. The bricks are made from various raw materials of fire clay, calcined chamotte, mullite etc . they are highly resistant to abrasion, spalling and corrosion. Because the bricks have low porosity, high strength, good resistance to thermal spalling and to abrasion and to creep, Jucos fireclay brick are applied for the linings of Coke Ovens, Glass furnace, Cement Rotary Kilns, Lime Kilns,Various Incinerators, Reheating Furnaces etc..
Fired Clay Refractory Industiral Brick refer to light-weight thermal insulation brick products with Al2O3 content of 30%-46%. With clay clinker or light clinker and plastic clay as the main principle, it is usually produced by the combustible method. It can also be produced by the chemical method or foam method to form a porous structure. The use temperature is 1200-1400℃. The refractory is characterized by high porosity, generally 40%-85%; low bulk density below 1.5g/cm3; low thermal conductivity, generally below 1.0W (m.K).
Advantage:
Good performance in high temp refractoriness under load
Lower thermal line expansion in high temp
Lower impurity content
Good thermal shock resistance performance
Excellent resistance in slag abrasion
Good cold crush strength
Application:
Fired Clay Refractory Industiral Brick can be used to furance contruction,blast furance/hot blast stove,steel foundries,furnace in the nonferrous metal industry,coke oven and gas furnace,galss industry,cement industry,safty lining of ladle and backup lining of boiler
Product Description:
|
Fired Clay Refractory Assembly Brick |
||||
|
Item |
Unit |
RN-42 |
HRN-42 |
HRN-48 |
|
AL2O3 % |
% |
≥42 |
≥42 |
≥48 |
|
Fe2O3 % |
% |
≤ 1.7 |
≤ 1.7 |
≤ 1.7 |
|
Refractoriness |
℃ |
≥1750 |
≥1750 |
≥1750 |
|
Bulk density |
g/cm3 |
≥2.15 |
≥2.15 |
≥2.35 |
|
Apparent porosity |
% |
≤ 24/23 |
≤ 24/21 |
≤ 24/21 |
|
cold crushing strength |
Mpa |
≥30 |
≥40 |
≥40 |
|
0.2MPa,Refractoriness under load,℃ |
℃ |
≥ 1400 |
≥ 1520 |
≥ 1550 |
|
Permanent linear change |
% |
0～-0.3 |
0～-0.3 |
0～-0.3 |
|
thermal shock resistance, |
cycle |
≥ 20 |
≥30 |
≥40 |
Packaging and shipping
Standard packing: waterproof inner packing + outer packing suitable for container transportation
